Product Description
Multi Spark CD Ignition System - 150DL
Built on high-tech microprocessor-controlled technology, the Intellitronix high performance Multi Spark Capacitive Discharge (CD) Ignition System is employed in street, track and off-road applications, where vehicle uptime is imperative. Designed for top-tier automotive performance, the Multi Spark CD Ignition is truly in a class all its own.
The Multi Spark CD Ignition System offers protection against system ignition failures and promotes compatibility features.
FEATURES
- Built-in self-protection system that monitors output current and internal operating temperatures, which provides protection from bad coils, faulty wiring, and system failures.
- Unlike other ignition systems on the market, the Prometheus goes into system protect-mode and does not self-destruct or damage other systems.
- Great for racing applications that do not use an alternator.
- User-adjustable Rev Limiter that works with 4-, 6- or 8-cylinder engines.
- Works with points, OEM, aftermarket electronic or magnetic crank systems.
- Uses less power than competitor ignition systems, while providing superior performance!
- Works with any negative ground and 12V electrical system with a distributor.
- Comes with a Tachometer Output wire that can also trigger a shift light or any add-on RPM activated devices.
OUTPUT VOLTAGE:
Primary 550V
Secondary 55,000V
SPARK ENERGY:
150 mJ up to 12,000 RPM
Only 750mA per 1000 RPM
DOWNLOADS
Installation Guide
