Product Description
1980-86 Ford Truck LED Digital Gauge Panel - DP1011
Your 1980-86 Ford Truck with have a new elegant look with a fabulous 80-86 Ford Truck LED Digital Replacement Gauge Panel from Intellitronix. The LED Digital dash come complete with direct fit printed circuit boards, custom fit "smoked" plexiglass faceplate, universal temperature, oil pressure, and speedometer sending units with sender and sensor for vehicles without electronic transmission or cruise control, and instructions for installation.
Speedometer reads up to 255 MPH and features odometer, trip meter, one-button calibration, regardless of tire size, gear ratio, or transmission, 0-60 time, 1⁄4 mile elapse time, and high speed recall, all with the push of a button. The speedometer can be used with electronic cruise control senders or with S9024 Ford speedometer sending unit included, if your vehicle is not equipped with a functional cruise control. The sensor may need to have mount and/or O-ring changed to fit correctly. It may be required to reuse speedometer gear from factory adaptor.
Tachometer reads 0-9900 RPM and in 100 RPM increments.
Water Temperature display with 18-255°F range with sender S8013 included. Please specify bushing size for sender as we normally send a 1/2 inch one, but we can send a 3/8 inch one instead upon request.
Oil Pressure display with 0-100 PSI range. Oil pressure sender included.
Voltmeter displays with 7.0-25.5 volt range and no sending unit is required.
Fuel Level display with 0-99% range in 1% increments and works with existing Ford fuel level sending unit.
The panels also feature turn signals and high beam indicator making it the ultimate way to keep the ride you love cruising through the times.
Easy Install, Lifetime Warranty, Great Price, & Gauges for your very special classic vehicle.
BEZEL NOT INCLUDED
FEATURES:
AVAILABLE COLORS: White, Red, Blue and Green
SPEEDOMETER READING: Order your speedometer in either MPH or KPH
ACCESSORIES: All required sending and sensor units are included.
DOWNLOADS
Installation Guide
