1967-72 Ford Truck LED Digital Gauge Panel - DP1009
Cruise down the avenue in your 1967-72 Ford Truck with a super looking 67-72 Ford Truck LED Digital Replacement Gauge Panel from Intellitronix. The LED Digital dash come complete with direct fit printed circuit boards, custom fit "smoked" plexiglass faceplate, universal temperature, oil pressure, and speedometer sending units with sender and sensor for vehicles without electronic transmission or cruise control, and instructions for installation.
The 1967-72 Ford Truck Digital Dash works with your factory fuel level sending unit and cruise control sender or electronic transmission output, if so equipped. Everything directly fits into your existing housing, but you may need to run some new wires to the speed sensor.
Speedometer reads up to 255 MPH and features odometer, trip meter, one-button calibration, regardless of tire size, gear ratio, or transmission, 0-60 time, 1⁄4 mile elapse time, and high speed recall, all with the push of a button. The speedometer can be used with electronic cruise control senders or with S9024 Ford speedometer sending unit included, if your vehicle is not equipped with a functional cruise control. The sensor may need to have mount and/or O-ring changed to fit correctly. It may be required to reuse speedometer gear from factory adaptor.
Tachometer reads 0-9900 RPM and toggles between speedometer and tachometer.
Water Temperature displays 100-300 °F range and includes sending unit S8013. Please specify bushing as we send a 1/2 inch one, but we can send a 3/8 inch one instead, upon request. Make a note on your order at checkout; otherwise, you will have to get the correct bushing on your own.
Oil Pressure reads 0-100 PSI range and the oil pressure sender is included.
Voltmeter displays 7.0-25.5 volt range and no sending unit is required.
Fuel Level displays 0-99% range in 1% increments and works with existing Ford fuel level sending unit.
The panel features turn signals and high beam indicator.
Easy Install, Lifetime Warranty, Great Price, & Gauges for your very special classic vehicle.
BEZEL NOT INCLUDED
AVAILABLE COLORS: White, Red, Blue and Green
SPEEDOMETER READING: Order your speedometer in either MPH or KPH
ACCESSORIES: All required sending and sensor units are included.
