Product Description
1992-1995 Jeep YJ LED Digital Gauge Panel - DP6013
Ride the wind in your classic Jeep YJ with a customized 1992-1995 Jeep YJ LED Digital Gauge Replacement Dash. The 92-95 Jeep YJ LED Digital Dash Panel Replacement by Intellitronix comes complete with direct fit printed circuit boards, custom fit "smoked" plexiglass faceplate, universal temperature, and oil pressure.
Speedometer reads 0-255 MPH and features odometer, trip meter, one-button calibration, regardless of tire size, gear ratio, or transmission, and 0-60 time, 1⁄4 mile elapse time, and high speed recall, all with the push of a button.
PLEASE NOTE: If using factory equipment, GPS (S9020) will be required for speed signal!
Tachometer displays 0-9900 RPM in 100 RPM increments.
Water Temperature displays 100-300°F includes S8013 sending unit. Please send a note to seller if you need a 3/8" bushing, because we send the more common 1/2" bushing--otherwise, you will have to supply the bushing on your own.
Oil Pressure reads 0-100 PSI range and includes oil pressure sending unit.
Voltmeter displays 7.0-25.5 volt range and no sending unit is required.
Fuel Level displays 0-99% range in 1% increments. Programmable for Jeep/Chrysler, Ford, GM, VDO (10-180 ohms) and aftermarket (240-33 ohms).
Clock not included.
The panel does not include turn signals, high beam, brake, or 4WD indicators, so you will need to retain the orginal indicators from your OEM dash.
Easy Install, Lifetime Warranty, Great Price, & Gauges for your very special classic vehicle.
BEZEL NOT INCLUDED
FEATURES:
AVAILABLE COLORS: White, Red, Blue and Green
SPEEDOMETER READING: Order your speedometer in either MPH or KPH
Upgrade your setup with these premium features:
GPS Speedometer Sending Unit: Accurate readings with a simple 3-wire hookup. Works with 4000, 8000, or 16000 PPM speedometers. Built-in GPS eliminates speed errors caused by tire or gear changes.
PLEASE NOTE: If using factory equipment, GPS (S9020) will be required for speed signal!
Universal Gauge Harness: Designed for performance and professional appearance, this 8' harness includes color-coded wires, quick-connects for easy removal, and all hardware needed for gauge wiring. Includes connectors for:
Water temp, oil pressure, tachometer, voltmeter, fuel level, speedometer, dash lights, turn indicators, and high beam indicator.
LS Swap Kit: Perfect for GM engines, includes 12mm & 16mm bushings and a 10K-1/2 watt resistor.
DOWNLOADS
Installation Guide
