Product Description
Raise eyebrows cruising down the street in your 1968 Chevy Chevelle complete with a new 68 Chevelle Analog Replacement Panel from Intellitronix. The 1968 Chevelle Analog Panel incorporates the latest in electronic gauges into one smashing dash that includes speedometer, tachometer for 8-, 6-, 4-cylinder, fuel level, voltmeter, oil pressure, and water temperature gauges.
The 1968 Chevelle Analog Dash works with any mechanical or electronic transmissions, or you can purchase a GPS speedometer sender separately from Intellitronix.
Speedometer reads up to 160 mph and includes odometer, trip meter, one button calibration, 0-60 time, ¼ mile elapsed time, and high-speed recall.
Tachometer displays 0–8000 RPM in 100 RPM increments.
Water Temperature displays a range of 100-260°F.
Oil Pressure shows a range of 0 – 100 PSI.
Voltmeter displays 10.0-18.0 volts range. No sending unit required.
Reads from Empty to Full in ¼ increments. User programmable to work with Ford, GM, Chrysler, VDO, and aftermarket 240-33 ohm industry standard fuel senders.
Turn signal indicators, high beam indicator, and sending units for speedometer S9024, water temperature S8013, and oil pressure S8434 are included along with clear acrylic, hardware, and complete installation instructions.
The analog dash features automatic nighttime dimming.
Easy Install, Lifetime Warranty, Great Price, & Gauges that bring your truck to the next level.
BEZEL NOT INCLUDED
FEATURES:
ACCESSORIES: All required sending and sensor units are included.
Upgrade your setup with these premium features:
GPS Speedometer Sending Unit: Accurate readings with a simple 3-wire hookup. Works with 4000, 8000, or 16000 PPM speedometers. Built-in GPS eliminates speed errors caused by tire or gear changes.
Universal Gauge Harness: Designed for performance and professional appearance, this 8' harness includes color-coded wires, quick-connects for easy removal, and all hardware needed for gauge wiring. Includes connectors for:
Water temp, oil pressure, tachometer, voltmeter, fuel level, speedometer, dash lights, turn indicators, and high beam indicator.
LS Swap Kit: Perfect for GM engines, includes 12mm & 16mm bushings and a 10K-1/2 watt resistor.
